Sliding Doors


We have a range of sliding doors to suit every type of property and can now install massive glass panes up to 3.2 metres wide and 4 metres height.

SUPERGLIDE

Superior thermal insulated and strong dual hollow aluminium horizontal sliding system with internal beads. Suitable for light / medium / heavy duty commercial applications and domestic areas requiring extreme performance.

Materials:

  • Extruded out of aluminium-alloy AlMgSi 0,5 F22 according to DIN 1725.
  • Tolerance according to DIN17618.

Finishing:

  • Electrostatic powder coating: according to the guidelines of APA-Qualicoat in most of the current RAL-colours.
  • Possible to colour in wood structure to imitate different woods (Powder coated according to Qualicoat). All coatings will be delivered with a certificate of guarantee for 15 years.
  • Anodisation: in satin or bronze colours with E.E.W.A./EURAS-Qualanod quality label.
  • Thermal break: The profiles consist of 2 aluminium extrusions which are separated from one another by polyamide strips PA 6.6.25 reinforced with glass fibre. A gluing thread, rolled and pushed in together with the thermal break profile, ensures a strong adhesion after melting and flowing, when the profiles are heated in the hardening furnace.

Details:

  • Built-in depth: outer frame 99 mm
  • Sealings: with PP-brushes
  • Glazing: from 4 to 29 mm
  • Wheels: ALIPLAST
  • Hardware: SOBINCO
  • Max. sash weight: 200 kg
  • Wheels: PVC
  • Double rail: Aluminium
  • Different combinations: 2-, 3-, 4- and 6-parted

Performance level according to STS 52.0:

  • Air transmission: PA3
  • Mechanical resistance to wind: PV3
  • Watertightness: PE3

Performance level according to UEATC:

  • Air transmission: A3
  • Mechanical resistance to wind: V3
  • Watertightness: E3

VISOGLIDE

Versatile thermal insulated aluminium horizontal sliding system with internal beads. Suitable for domestic and light / medium / heavy duty commercial applications.

  • To separate terrace and living quarters in houses and flats.
  • Separations for conservatories looking out into the garden and to create space in a passage way.

Materials:

  • Extruded out of aluminium-alloy AlMgSi 0,5 F22 according to DIN 1725.
  • Tolerance according to DIN17618.

Finishing:

  • Electrostatic powder coating: according to the guidelines of APA-Qualicoat in most of the current RAL-colours.
  • Possible to colour in wood structure to imitate different woods (Powder coated according to Qualicoat). All coatings will be delivered with a certificate of guarantee for 15 years.
  • Anodisation: in satin or bronze colours with E.E.W.A./EURAS-Qualanod quality label.
  • Thermal break: The profiles consist of 2 aluminium extrusions which are separated from one another by polyamide strips PA 6.6.25 reinforced with glass fibre. A gluing thread, rolled and pushed in together with the thermal break profile, ensures a strong adhesion after melting and flowing, when the profiles are heated in the hardening furnace.

Details:

  • Built-in depth: outer frame 99 mm
  • Sealings: with PP-brushes
  • Glazing: from 4 to 29 mm
  • Wheels: ALIPLAST
  • Hardware: SOBINCO
  • Max. sash weight: 200 kg
  • Wheels: PVC
  • Double rail: Aluminium
  • Different combinations: 2-, 3-, 4- and 6-parted

Performance level according to STS 52.0:

  • Air transmission: PA3
  • Mechanical resistance to wind: PV3
  • Watertightness: PE3

Performance level according to UEATC:

  • Air transmission: A3
  • Mechanical resistance to wind: V3
  • Watertightness: E3
